Welded Wire Mesh
HOME >> PRODUCTS >> Wire Mesh >> Welded Wire Mesh
Description: Our Welded Wire Mesh Rolls are engineered for superior strength, durability, and versatility. Manufactured by resistance-welding high-strength longitudinal and transverse steel wires at every intersection, this mesh delivers consistent performance across industrial, agricultural, and commercial applications. Available in various materials, coatings, and sizes, our welded mesh rolls combine functionality with ease of installation.
Model No.:JH66458Supply Nature:Factory DirectPRODUCTS
NEWS
Product Details
Welded wire mesh is produced from a series of longitudinal and transverse high strength steel wires, resistance welded at all intersections. The manufacturing process can be varied to accommodate various style changes and dimensions. Normally, Welded wire mesh are produced in self color and galvanized or PVC Coated after manufacture. Some specifications are produced from galvanized wire and stainless steel. It’s available in rolls, standard sheets and cut-to-size.
Material: Low carbon steel, galvanized wire, Stainless steel wire.
Mesh inch | Mesh mm | Gauge | Gauge mm | Assortments Available |
1/4"x 1/4" | 6.35x6.35 | 23G | 0.64 | Hot-dipped galvanized after welding Hot-dipped galvanized before welding Electro-galvanized after welding Electro-galvanized before welding PVC Coated after welding Stainless steel welded mesh |
1/2"x 1/2" | 13 x 13 | 16G | 1.5 | |
1"x 1" | 25 x 25 | 8G | 3.94 | |
1"x 1" | 25 x 25 | 10G | 3 | |
1"x 1" | 25 x 25 | 12G | 2.44 | |
1 1/2"x 1 1/2" | 38 x 38 | 10G | 3 | |
2"x 1" | 50 x 25 | 10G | 3 | |
2"x 1" | 50 x 25 | 12G | 2.44 | |
2"x 2" | 50 x 50 | 6G | 4.69 | |
2"x 2" | 50 x 50 | 8G | 3.94 | |
2"x 2" | 50 x 50 | 10G | 3 | |
2"x 2" | 50 x 50 | 12G | 2.44 | |
3"x 3" | 75 x 75 | 6G | 4.69 | |
3"x 3" | 75 x 75 | 8G | 3.94 | |
3"x 3" | 75 x 75 | 10G | 3 | |
4"x 4" | 100 x 100 | 8G | 3.94 | |
Above wire diameter is for reference, most specifications can be customized. | ||||
Applications: Mining, Fencing, Decoration, Machinery protection, Animal cage ,Agriculture, Sieving Etc.
